ADMET DIC system is a fully integrated solution that utilizes optimized correlation algorithms to provide non-contact, full-field, two-dimensional displacement and strain data for mechanical testing on planar specimens. In-plane displacements are measured at every point within the area of interest, and the full-field strain field is computed and displayed to easily identify strain concentrations.
Specimen sizes ranging from microscopic to very large scale can be measured by simply adjusting optics. Sub-micron displacements can be measured, and local strains from 50 microstrain to over 2500% are achievable with extremely low noise levels and high accuracy.
Digital Image Correlation (DIC) system analysis software includes post-processing features such as minimum/maximum, mean and standard deviation, time-slice extraction, stress-strain curve generation, data extraction along lines and more.
Optical surface deformation measurements can be used for but not limited to material testing including fracture mechanics, biaxial and tensions tests, FEA validation such as strain localization around cracks and notches and general component testing.
Just Ask!
Have questions about how Digital Image Correlation can provide the capabilities you need for your testing application?
